Fastener PUSZ-LIN-ZD, silver, stainless steel

Ref No: 42257
  • Lengthwise suspension on a wire
  • High lifting capacity
  • Single pole conductivity possible
Conducting electricity
Color
silver
  • Lengthwise suspension on a wire
  • High lifting capacity
  • Single pole conductivity possible
Application
  • - for suspending LED lighting fixtures
Mounting
  • - to the lighting fixture, with a large lock
  • - to the wire, using a plug and a clamp sleeve
Technical drawing
Fastener PUSZ-LIN-ZD, silver, stainless steel stainless steel Technical drawing - 42257
Technical specification
Material
stainless steel
Diameter
0.6"
Conducting electricity
Yes
Working temperature
131°F
Lifting capacity
66 lb
Maximum current intensity
12 A
Power loss
0.05 V
Width x Height
0.6" x 1.6"
Related products
Product name Material Color Ref No
Wire FI-1,35mm
copper, FEP
silver
Z70310
FI-1 39.4" Stainless steel wire
steel
silver
C24522N00
Wire CU FI 0,95 mm
steel, copper
silver
Z70240
