Fastener PUSZ-LIN-MR

Ref No: C28122N00
  • Lengthwise suspension on a wire
  • High lifting capacity
  • Single pole conductivity possible
  • Fixing screw flush with the extrusion surface
Conducting electricity
Color
silver
  • Lengthwise suspension on a wire
  • High lifting capacity
  • Single pole conductivity possible
  • Fixing screw flush with the extrusion surface
Application
  • - for suspending LED lighting fixtures
Mounting
  • - to the lighting fixture, using a countersunk screw (included)
  • - to the wire, using a plug and a clamp sleeve
Technical drawing
Fastener PUSZ-LIN-MR stainless steel Technical drawing - C28122N00
Technical specification
Material
stainless steel
Conducting electricity
Yes
Working temperature
131°F
Lifting capacity
66 lb
Maximum current intensity
12 A
Power loss
0.05 V
Width x Height
0.6" x 1.5"
